Asus PRIME H610M-R-SI LGA1700 H610 DP

Šifra artikla: PRIME H610M-R-SI

GOTOVINA: 77,58€

NA RATE: 83,01€

Ispiši proizvod

Specifikacije

General
Product Type:	Motherboard – micro ATX
Chipset Type:	Intel H610
Processor Socket:	LGA1700 Socket
Max Processors Qty:	1
Compatible Processors:	(supports 12th and 13th Generation Intel Core / Pentium Gold / Celeron)
Supported RAM
Max Size:	96 GB
Technology:	DDR5
Bus Clock:	4800 MHz, 5000 MHz, 5200 MHz, 5400 MHz, 5600 MHz
Supported RAM Integrity Check:	Non-ECC, on-die ECC
Registered or Buffered:	Unbuffered
Features:	Dual channel memory architecture, Intel Extreme Memory Profiles (XMP)
Audio
Type:	HD Audio (8-channel)
Compliant Standards:	High Definition Audio
LAN
Network Interfaces:	Gigabit Ethernet
Expansion / Connectivity
Expansion Slots:	1 x CPU 2 x DIMM 288-pin 1 x PCIe 4.0 x16 1 x PCIe 3.0 x1 1 x M.2 socket (2242/2260/2280 M.2 Key M slot)
Storage Interfaces:	SATA-600 -connectors: 4 x 7pin Serial ATA PCIe 3.0 -connectors: 1 x M.2
Interfaces:	1 x HDMI 1 x VGA 1 x DisplayPort 2 x USB 2.0 2 x USB 3.2 Gen 1 1 x LAN (Gigabit Ethernet) 1 x PS/2 mouse 1 x PS/2 keyboard 1 x microphone – mini-jack 1 x audio line-out – mini-jack 1 x audio line-in – mini-jack
Internal Interfaces:	2 x USB 3.2 Gen 1 – header 4 x USB 2.0 – header 1 x audio – header 1 x serial – header 1 x parallel – header 1 x speaker – header 1 x SPI – header
Power Connectors:	24-pin main power connector, 4-pin ATX12V connector
Features
BIOS Type:	AMI
BIOS Features:	UEFI BIOS, ASUS UEFI BIOS EZ Mode, ASUS EZ Flash 3
Sleep / Wake Up:	Wake on LAN (WOL), wake on PME
Hardware Features:	Intel Turbo Boost Max Technology 3.0, Intel Turbo Boost Technology 2.0, CrashFree BIOS 3, ASUS EZ DIY, aluminium heatsink design, ASUS Q-Design, Q-DIMM, Q-LED Core, Q-Slot, ASUS 5X PROTECTION, ASUS DIGI+ VRM, ASUS Overvoltage Protection, ASUS SafeSlot Core, ASUS Stainless Steel Back I/O, LANGuard, ASUS EPU (Energy Processing Unit), DIY Friendly Design
Miscellaneous
Included Accessories:	IO shield
Width:	22.6 cm
Depth:	19.5 cm
Package Type:	Bulk
